Ricoh IM C2000 Series User Manual

5. Check the domain name, workgroup name and login user name, and write down the
information in [2] on the check sheet.
CKX007
When the screen shown above is displayed, fill in the sheet as follow:
Domain name/workgroup name
[2]
Computer login user name
USERDNSDOMAIN
[ abcd-net.local ]
USERDOMAIN
[ ABCD-NET ]
TYamada
DZC524
"USERDNSDOMAIN" is not displayed when the login user who executed the command is a local
user.
6. Check the login password on the computer, and write down the information in [3] on the
check sheet.
The required information on the computer is confirmed. Now create a shared folder on your
computer and specify the access permissions of the folder.
Creating a Shared Folder (Windows)
Create a shared folder on the Windows Desktop and specify the access permissions of the folder.
1. Log on to Windows as a user with administrative privileges.
2. Create a new folder in Windows Explorer and write down the folder name in [4] on the
check sheet.
3. Right-click the created folder, and then click [Properties].
5. Scan
150

Ricoh IM C2000 Series Specifications

General

Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	2, 300 sheets
Duplex Printing	Yes
Standard Memory	2 GB
Power Consumption (Maximum)	1.3 kW
Copy Speed (Color)	20 cpm
Copy Speed (Mono)	20 cpm
Copy Resolution	600 x 600 dpi
Print Speed	20 ppm
Scan Resolution	600 dpi
Connectivity	USB, Ethernet, Wi-Fi
First Print Time (Color)	7.5 seconds or less
Supported Paper Sizes	A3, A4, A5, B4, B5
Paper Weight	52 - 300 gsm
Hard Disk Drive	320 GB
Power Source	50/60Hz
Fax Resolution	200 x 200 dpi
