Ricoh IM C2000 Series User Manual

Specifications for IEEE 1284 Interface Board
Item Specifications
Transmission spec IEEE 1284
Required cable Standard IEEE 1284 compliant Micro Centronics 36 pin cable
Specifications for Wireless LAN Board
• Note that the available channels (frequency ranges) and locations to use the wireless LAN are
subject to the regulations of the country or region where the printer is used. Be sure to use the
wireless LAN according to the applicable regulations.
Item Specifications
Transmission spec Based on IEEE 802.11a/b/g/n (wireless LAN)
Protocol TCP/IP
Transmission rate 2.4 GHz band: 1–130 Mbps
Frequency range (Center
Frequency)
2412–2472 MHz (1–13 channels)
Ad-hoc mode Channel
Frequency range (Center
Frequency)
2412–2462 MHz (1–11 channels)
Transmission mode • Ad-hoc mode
• Infrastructure mode
• Direct Connection Mode
• Direct Connection: Group Owner Mode
• Web Image Monitor is supported.
• The transmission rates of 130 Mbps in the 2.4 GHz band is the theoretical values of the wireless
LAN specification. The actual transmission rate may be lower, depending on the operating
environment.
List of Specifications
359

Ricoh IM C2000 Series Specifications

General

Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	2, 300 sheets
Duplex Printing	Yes
Standard Memory	2 GB
Power Consumption (Maximum)	1.3 kW
Copy Speed (Color)	20 cpm
Copy Speed (Mono)	20 cpm
Copy Resolution	600 x 600 dpi
Print Speed	20 ppm
Scan Resolution	600 dpi
Connectivity	USB, Ethernet, Wi-Fi
First Print Time (Color)	7.5 seconds or less
Supported Paper Sizes	A3, A4, A5, B4, B5
Paper Weight	52 - 300 gsm
Hard Disk Drive	320 GB
Power Source	50/60Hz
Fax Resolution	200 x 200 dpi
