3. Paper guides
When loading paper in the bypass tray, align the paper guides with the edges of the paper.
4. Extender
Pull this extender out when loading paper larger than A4 , 8
1
/
2
× 11.
5. Lower right cover
Open this cover to remove jammed paper.
6. Right cover
Open this cover to remove jammed paper.
7. Vents
Holes for ventilating the inside the machine to prevent the internal components from overheat.
After large-volume printing, the ventilation fan may continue to work to lower the temperature inside the
machine.
Rear and Left View (mainly Europe) (mainly North
America)
DZC163
4
1
2
3
1. USB2.0 Interface Type A
Use the port to connect the IC card authentication device.
2. USB2.0 Interface Type B
Use the port to connect the machine and the computer with the USB cable.
Guide to Names and Functions of Components
17

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh IM C2000 Series and is the answer not in the manual?

Ricoh IM C2000 Series Specifications

General IconGeneral
Print Resolution1200 x 1200 dpi
Maximum Paper Capacity2, 300 sheets
Duplex PrintingYes
Standard Memory2 GB
Power Consumption (Maximum)1.3 kW
Copy Speed (Color)20 cpm
Copy Speed (Mono)20 cpm
Copy Resolution600 x 600 dpi
Print Speed20 ppm
Scan Resolution600 dpi
ConnectivityUSB, Ethernet, Wi-Fi
First Print Time (Color)7.5 seconds or less
Supported Paper SizesA3, A4, A5, B4, B5
Paper Weight52 - 300 gsm
Hard Disk Drive320 GB
Power Source50/60Hz
Fax Resolution200 x 200 dpi
