Image Creation
M065/M066 4-32 SM
4.5.6 WASTE TONER BOTTLE FULL SENSOR
1. Inner left rear cover ( p.4-11)
2. Sensor bracket [A] (
x 2, x 1)
3. Waste toner bottle full sensor [A] ( x 1, hooks)
