Ricoh M065 - Itb Contact Motor

Image Transfer
SM 4-45 M065/M066
Replacement
and
Adjustment
4.6.3 ITB CONTACT MOTOR
1. Right cover ( p.4-4)
2. ITB contact motor unit [A] (
x 2, x 1, x 1)
3. ITB contact motor [A] ( x 2)
 Apply a small amount of "Silicone Grease G501" to the gear of the motor as
shown above.
