Drive Unit
SM 4-67 M065/M066
Replacement
and
Adjustment
4.8.8 FRONT DOOR SENSOR
1. Right cover ( p.4-4)
2. Top cover (
p.4-6)
3. Inner right front cover (
p.4-12)
4. Front door sensor [A] ( x 1, hooks)
