Jam Detection
M065/M066 6-2 SM Appendix
Jam Code
SP
Display Description
LCD
Display
detect paper from tray 1.
7504 12 V-Transport 2: ON
Vertical transport sensor 2 does not
detect paper from tray 2.
Y
7504 13 V-Transport 3: ON
Vertical transport sensor 3 does not
detect paper from tray 3.
Y
7504 14 V-Transport 4: ON
Vertical transport sensor 4 does not
detect paper from tray 4.
Y
7504 17 Regist Sensor: ON
Registration sensor does not detect
paper.
A
7504 18 Fusing Ent: ON
Fusing entrance sensor does not detect
paper.
B
7504 19 Fusing Exit: ON
Fusing exit sensor does not detect
paper.
C
7504 20 Paper Exit: ON Paper exit sensor does not detect paper. C
7504 25 Duplex Exit: ON
Duplex exit sensor does not detect
paper.
Z
7504 27 Duplex Ent: ON
Duplex entrance sensor does not detect
paper.
Z
7504 28 Inverter Sn: ON Inverter sensor does not detect paper. Z
7504 47 P-Feed 1: OFF Paper feed sensor 1 does not turn off. A
7504 48 P-Feed 2: OFF Paper feed sensor 2 does not turn off. Y
7504 49 P-Feed 3: OFF Paper feed sensor 3 does not turn off. Y
7504 50 P-Feed 4: OFF Paper feed sensor 4 does not turn off. Y
7504 51 V-Transport 1: OFF
Vertical transport sensor 1 does not turn
off.
A
7504 52 V-Transport 2: OFF
Vertical transport sensor 2 does not turn
off.
Y
