Ricoh MP 2014AD - Pressure Roller and Bushings; Thermostat

Fusing
SM 4-44 D245/D246/D247
4.10.8 THERMOSTAT
1. Hot roller unit (page 4-42)
2. Thermostat [A] (
x 2)
4.10.9 PRESSURE ROLLER AND BUSHINGS
1. Separate the hot roller section from the pressure roller section (page 4-40).
2. Fusing entrance guide plate (page 4-40)
3. Two pressure arms [A] (bracket x 1,
x 1 for each arm)
4. Two bushings [B]
5. Pressure roller [C]
