Product Overview
SM 1-7 D245/D246/D247
Product
Information
Laser Unit/ PCDU/ Fusing Unit
No. Description No. Description
1 Laser unit 5 Thermostat
2 TD sensor 6 Thermistor (Center)
3 ID sensor 7 Thermistor (End)
4 Fusing lamp
