Ricoh MP 2014AD - Drive Side; Driven Side; Registration Roller

Paper Feed Section
SM 4-49 D245/D246/D247
Replacement
and Adjustment
4.12.3 REGISTRATION ROLLER
Driven Side
1. PCDU (page 4-30)
2. Front right cover (page 4-3)
3. Right rear cover (page 4-5)
4. Registration clutch (page 4-68)
5. Open the right door.
6. Feed roller cover [A] (
x 1)
7. Registration roller [B] (
x 3)
Drive Side
1. ID sensor cover (page 4-56)
2. Registration roller [A] (Cap x 1, Gear x 1,
x 1, Bushing x 1)
