Ricoh MP 2014AD - Electrical Component

Product Overview
SM 1-11 D245/D246/D247
Product
Information
Electrical Component
No. Description No. Description
1 Exhaust fan 6 PSU
2 Door switch (Front door/Right door) 7 Main power switch
3 Right door switch 8 MPU
4 Main fan 9 HVP
5 PFU main board (Option)
