Ricoh MP 2014AD - Paper Feed Unit

Product Overview
SM 1-6 D245/D246/D247
Paper Feed Unit
No. Description No. Description
1 Registration clutch 5 Registration sensor
2 Paper feed clutch (Main) 6 Paper feed sensor (Option)
3 Paper feed clutch (Option) 7 Paper end sensor (Option)
4 Transport motor (Option) 8 Paper end sensor (Main)
