Ricoh MP 2014AD - Page 161

Engine SP Mode
SM 5-17 D245/D246/D247
System
Maintenance
2-201-002
P Pattern Revisio *ENG [0 to 4 / 0 / 1 / step]
0: N(Normal)
1: H(Drak)
2: L(Light)
3: HH(Darker)
4: LL(Lighter)
Adjusts the voltage applied to the development roller for the ID sensor
pattern. The voltage applied is obtained by adding SP2-201-002 to
SP2-201-001. The setting affects ID sensor pattern density, which in turn
affects the toner supply.
2-201-003
ID Sensor Pattern *ENG DFU
2210 [Bias OFF Time] DFU
2-210-001
Charge Bias 2nd *ENG -
2-210-002
Deve Bias 2nd *ENG -
2211 [PCU Reverse Inter] DFU
2-211-001
- *ENG -
2213 [After Toner End] DFU
2-211-001
End Limits *ENG -
2220 [Process Data Dila]
Displays:
a) Vt: the current TD sensor output value and
b) Vref: the target TD output value Vts (SP2-926) + correction for ID sensor
output.
The TD sensor output value changes every copy. If a > b, toner is supplied
to the development unit.
2-220-001
Vsp *ENG [0.00 to 9.99 / 0.00 / 0.01 vol / step]
2-220-002
Vsg *ENG [0.00 to 9.99 / 0.00 / 0.01 vol / step]
