Ricoh MP 2014AD - Page 211

SC Code Descriptions
SM 6-13 D245/D246/D247
Troubleshooting
SC No. Level Error Name/Error Condition/Major Cause/Solution
361-01 B TD sensor output upper limit error (K)
TD sensor output:
The Vt (SP2-220-004) output continuously exceeds the upper
limit threshold value (SP2-992-001) for the time of the upper
limit threshold (SP2-992-003).
TD sensor is not connected correctly.
 Check if the TD sensor connector is connected.
 Check the harness of the TD sensor (disconnected, etc.).
 Replace the development unit if some error is detected.
SC No. Level Error Name/Error Condition/Major Cause/Solution
362-01 B TD sensor output lower limit error (K)
TD sensor output:
The Vt (SP2-220-004) output is continuously below the lower
limit threshold value (SP2-992-002) for the time of the lower limit
threshold (SP2-992-004).
TD sensor is not connected correctly.
 Check if the TD sensor connector is connected.
 Check the harness of the TD sensor (disconnected, etc.).
 Replace the development unit if some error is detected.
