READ THIS FIRST
Safety and Symbols
Replacement Procedure Safety
Turn off the main power switch and unplug the machine before beginning any of the
replacement procedures in this manual.
Symbols and Abbreviations
This manual uses several symbols and abbreviations. The meaning of those symbols and
abbreviations are as follows:
Screw
Shoulder screw
Black screw (TCRU)
Connector
FFC (Flat Film Connector)
Harness clamp
Clip
E-ring
C-ring
Timing belt
Spring
SEF Short Edge Feed
LEF Long Edge Feed
