Rigol DHO800 Series User Manual

Figure 18.2 MarkTable Display ..........................................................................................194
Figure 18.3 Navigation Menu ........................................................................................... 195
Figure 18.4 Simplified Navigation Menu ...................................................................... 195
Figure 18.5 "Search Event" Navigation Setting Menu ..............................................196
Figure 18.6 "Frame Segment" Navigation Setting Menu ........................................196
Figure 19.1 Display Setting Menu ................................................................................... 198
Figure 20.1 Image Saving Setting Menu .......................................................................202
Figure 20.2 Waveform Saving Setting Menu ...............................................................204
Figure 20.3 Setup Saving Setting Menu ........................................................................205
Figure 20.4 Load Setting Menu ........................................................................................210
Figure 20.5 Upgrade Menu ................................................................................................211
Figure 20.6 Disk Management Interface .......................................................................212
Figure 21.1 Self-calibration Menu ................................................................................... 220
Figure 21.2 Quick Menu ......................................................................................................221
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
XI

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
