Rigol DHO800 Series User Manual

Statistics
Click or tap the
Statistic on/off switch to enable or disable the statistical result
display. You can also click or tap
at the lower-right of the measurement item in
the "Result" sidebar to expand the label to display all the statistical items. Click or tap
to collapse the label. The figure below shows the displayed results after the
Statistic of period measurement is enabled.
• Click or tap any measurement item in the "Result" sidebar at the right side of the
screen and a window is displayed. Click or tap
Reset Stat. to clear the history
statistics data and makes statistics again. You can also click or tap
Reset Stat. in
the measurement setting menu.
• Click or tap the input field of
Count and use the pop-up numeric keypad to set
the count value. You can also use the corresponding multipurpose knob to set
the value. Its range is from 2 to 100000. Its default value is 1000.
10.2.4 Remove the Measurement Results
This oscilloscope allows you to delete the measurement results of the parameters.
• In
Measure setting menu, click or tap Remove to delete the currently selected
measurement item that you've added; click or tap
Remove All to delete all the
displayed measurement items.
• Click or tap any measurement item in the "Result" sidebar at the right side of the
screen and a window is displayed. Click or tap
Remove to delete the currently
Measurements
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
139

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
