Rigol DHO800 Series User Manual

Window Transparency
In the
Display setting menu, drag the slider of Window Transparency to set the
window transparency. The default is 50%, and the range available is from 0% to 100%.
Cursor Brightness
In the
Display setting menu, drag the slider of Cursor Brightness to set the cursor
brightness. The default is 80%, and the range available is from 0% to 100%.
19.6 Show Scale
In the Display setting menu, click or tap the Show Scale on/off switch to enable or
disable scale display on the screen. By default, it is ON.
19.7 Color Grade
In the Display setting menu, click or tap the Color Grade on/off switch to enable or
disable the color grade display. By default, it is OFF.
When it is enabled, different colors are displayed on the screen to indicate the times
of data acquisition or acquisition probability.
19.8 Waveform Freeze
In the Display setting menu, click or tap the Waveform Freeze on/off switch to
enable or disable the waveform freeze function. By default, it is ON.
When the function is enabled, the oscilloscope displays the waveform after multiple
sampling and superposition when sampling is stopped. You can click or tap the
STOP/RUN button at the upper-right side of the screen or press the front-panel
key to stop sampling. If this function is disabled, the last triggered waveform is
displayed.
Display Control
DHO800 User Guide
200
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
