Rigol DHO800 Series User Manual

21
System Utility Function Setting
In the Utility menu, you can set the I/O parameters and the system-related function
parameters. You can enter the "Utility" menu in the following ways.
• Click or tap the Notification Area at the lower-right corner of the screen. Then
the Utility menu is displayed.
• Click or tap
> Utility to enter the Utility menu.
21.1 I/O Setting
In Utility menu, click or tap IO to enter the I/O setting menu to configure the
following parameters.
Network Status
Different prompts will be displayed according to the current network connection
status.
• Network Config Succeeded!
• Acquiring IP...
• IP Conflict!
• DISCONNECTED
• DHCP Config Failed
• Read Status Fail!
• CONNECTED
• Invalid IP
• IP lost
• Please wait...
MAC Address
For each instrument, the MAC address is unique. When assigning the IP address for
the instrument, the system uses the MAC address to identify the instrument.
VISA Address
Displays the VISA address currently used by the instrument.
System Utility Function Setting
DHO800 User Guide
214
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
