15.1.2 Bus Setting
Set the Bus
Click or tap the drop-down button of
BUS to select the desired bus. Available options
include analog channels CH1-CH4. You can also self-define the bus.
Table 15.1 Bus Setting
Bus Width Bit X Channel Remarks
CH1 1 0 CH1
Width, Bit X, and CH are set
automatically, and you
cannot modify them.
CH2 1 0 CH2
Width, Bit X, and CH are set
automatically, and you
cannot modify them.
CH3 1 0 CH3
Width, Bit X, and CH are set
automatically, and you
cannot modify them.
CH4 1 0 CH4
Width, Bit X, and CH are set
automatically, and you
cannot modify them.
User
1 (Default)
to 4
0 (Default) - -
Set the Width
When the "BUS" setting is set to "User", you can set the bus width. Click or tap the
input field of
Width, and then use the pop-up numeric keypad to set the width. You
can also use the corresponding multipurpose knob to set the value.
Specify data channel for each bit
When the "BUS" setting is set to "User", you can specify the data channel for each bit.
Click or tap
Bit X set the bit of the channel. By default, 0 is selected. Its available
range is from 0 to (width - 1).
Click or tap the drop-down button of
CH to select the data channels for a bit.
Available sources include analog channels CH1-CH4.
Protocol Decoding
DHO800 User Guide
170
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
