- USB storage device icon: When a USB storage device is detected, will be
displayed.
- LAN icon: When the LAN interface is successfully connected,
is displayed.
- Sound icon: In the "Utility" menu, click or tap Setup > Beeper to enable or
disable the sound. When on,
will be displayed; when off, will be
displayed. You can simply click or tap the icon to enable or disable the sound.
- Remote control icon: When you use Web Control to control the instrument
remotely,
will be displayed.
11. Math Labels
- Displays the on/off states of Math1-Math4.
- Click or tap
M1-M4 labels to display the on/off state, operation type, and
vertical scale for Math1-Math4.
12.
Channel Labels
- Display the channel on/off status.
- Display the channel coupling mode.
- Display the vertical scale.
- Display the vertical offset.
- Click or tap the label to enable/disable the corresponding channel or open the
Vertical menu.
NOTE
As DHO802/DHO812 is a two-channel model, it only provides two channel labels.
13. Function Navigation Icon
Click or tap the icon to open the function navigation menu in which you can
access the specified function menu by clicking or tapping the corresponding
function key.
4.5 Touch Screen Gestures
The instrument's large capacitive touch screen makes operation and configuration
easy and flexible. The highly sensitive user interface designed for touch has a strong
waveform display capability, bringing an extraordinary user experience. The actions
Quick Start
DHO800 User Guide
26
