20
Store and Load
You can save the current setups, waveforms, screen image, and parameters of the
oscilloscope to the internal memory or external USB storage device (such as USB
storage device) in various formats and recall the stored setups or waveforms when
necessary. You can also load the upgrade software to the system and perform the
upgrade operation for the instrument.
You can also copy, delete, or rename the specified type of file from the internal
memory or external USB storage device via the disk management menu.
This oscilloscope provides one USB HOST interfaces on the front panel, which can be
connected to the USB storage device for external storage. The USB storage device
connected is marked as "Removable USB Disk (D)".
20.1 To Enter the Storage Menu
You can enter the storage setting menu in the following ways.
• Click or tap the function navigation icon
at the lower-left corner of the
screen, and then select
Storage to enter the storage setting menu.
• Click or tap the
Storage button on the toolbar to enter the storage setting
menu.
In the
Storage setting menu, there are three sub-menus (Save, Load, and Upgrade)
for you to choose. Select the specified sub-menu and configure the corresponding
parameters.
20.2 To Save a File
In the Storage menu, click or tap the Save tab to enter the save setting menu. In this
menu, you can save the image, waveform, or setup files.
20.2.1 To Save Image
In the Storage menu, click or tap the Save tab to enter the save operation menu. In
this menu, click or tap the drop-down button of
Choose to select "Save Image" to
enter the "Save Image" setting menu. Set the relevant parameters and save the image
to the internal or external memory.
Store and Load
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
201
