Rigol DHO800 Series User Manual

CAUTION
Please do not insert other objects into the security lock hole to avoid damaging the
instrument.
4.8 To Use the Built-in Help System
The built-in help file provides information about the functions and menu
introductions of the instrument. Click or tap
> Help to enter the help system.
In the help system, you can get its help information by clicking on or tapping the link
for the specified chapter.
Quick Start
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
35

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
