Rigol DHO800 Series User Manual

Clear Count
When "Totalize" is selected as the measurement item, the oscilloscope measures the
count of edge events on the signal. At this time, click or tap
Clear Count to clear the
measurement results and start the measurements again.
Statistics Results
When "Frequency" or "Period" is selected, click or tap the
Statistic on/off switch to
turn on/off displaying all statistical items. When enabled, all the statistical results will
be displayed in the "Counter" label in the "Result" bar.
11.2.2 Reset Statistics
Click or tap the "Counter" label in the "Result" bar at the right section of the screen
and a window is displayed. Click or tap
Reset Stat. in the window to reset the
statistics.
11.2.3 Remove the Measurement
Click or tap the "Counter" label in the "Result" bar at the right section of the screen
and a window is displayed. Click or tap
Remove to clear the measurement results. The
"Counter" label disappears from the "Result" bar accordingly. You can also click or tap
Remove in the counter setting menu to disable the function.
Digital Voltmeter (DVM) and Frequency Counter
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
153

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
