Rigol DHO800 Series User Manual

• BandStop: click or tap the ωc1 input field and use the pop-up numeric keypad
to set the lower limit frequency. Click or tap the
ωc2 input field and use the pop-
up numeric keypad to set the upper limit frequency. You can also use the
corresponding multipurpose knob to set the lower/upper limit frequency.
The settable ranges of the upper and lower limit frequencies are related to the Math
sample rate (displayed at the bottom of the screen when the Math function is
enabled). The sample rate of the analog channel or the changes of the memory depth
can affect the Math sample rate.
Label
It is used to set the label for the math operation results. For setting methods, refer to
descriptions in
To Turn the Channel Label Display On/Off .
Expand
The oscilloscope supports two vertical expansion modes: GND (default) and Center.
• GND: When the vertical scale is changed, the math operation waveform will
expand or compress about the ground level of the signal.
• Center: When the vertical scale is changed, the math operation waveform will
expand or compress about the center of the display.
Grid
For setting methods, refer to the descriptions in
To Set the Screen Grid .
Math Operation
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
125

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
