Rigol DHO800 Series User Manual

reference waveform to the internal memory or external USB storage device. Then
click or tap
Save to complete the save operation. For details about the disk
management operation, refer to the
Disk Management section in Store and
Load
.
TIP
• Only when the reference waveform is saved, can this export function be valid.
• For the ".bin" format file, refer to
Binary Data Format (.bin) .
Import from Internal or External Memory
You can import the stored reference waveform file from the internal memory or
external USB storage device to the instrument and display the file on the screen.
Click or tap
Import to enter the reference waveform file loading interface.
• Set the Format
The file format of the reference waveform is specified as "*.ref" which is
displayed in
Format.
• Set the Load Path
Click or tap the input field of
File Path, then the disk management interface is
displayed.
Through the disk management menu, you can load the current reference
waveform to the waveform view of the oscilloscope. Then click or tap
Load to
complete the load operation. For details about the disk management operation,
refer to the
Disk Management section in Store and Load .
Reference Waveform
DHO800 User Guide
162
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
