Click or tap the "Start Frame" input field in Figure 17.2 to set the start frame for
playing back the waveforms. You can also use the corresponding multipurpose
knob to set the value. The default is 1, and the maximum value is the maximum
number of frames recorded.
5. End Frame
Click or tap the "End Frame" input field in
Figure 17.2 to set the end frame for
playing back the waveforms. You can also use the corresponding multipurpose
knob to set the value. The default is the number of frames of the recorded
waveforms.
6. Current Frame
When the playing is stopped, click or tap the "Current" input field in
Figure 17.2 to
set the currently displayed frame with the pop-up numeric keypad. You can also
use the corresponding numeric keypad to set the value. The maximum allowed is
the number of recorded frames.
Waveform Recording and Playing
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
191

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
