Rigol DHO800 Series User Manual

click or tap the play/stop key, it plays from the "Start Frame" and the number of
frames that can display on each screen page is (End Frame-Start Frame+1).
For example, if you set the start frame to 3 and the end frame to 9, it will play
from the 3rd frame and displays 7 frames at a page.
• Click or tap
in "Navigation" menu or press the front-panel key to start/
stop playing through the frames between the
Start Frame and End Frame.
During playout, you can click or tap
to play backward or to play forward.
The playout automatically stops when it reaches the left or right edges. When it
stops, you can click or tap
/ to go forward or backward. You can also click
or tap
to go to the first page or to go to the last page. The current
page/total pages is indicated in
Current Page.
TIP
During segment playing, you are not allowed to change the start/end frame.
Search and Navigation
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
197

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
