Rigol DHO800 Series User Manual

Label Knob Label Knob
Horizontal
SCALE
Horizontal Scale
Knob
2
Multipurpose
Knob 2
Vertical
POSITION
Vertical Position
Knob
LEVEL
Trigger Level Knob
Vertical
SCALE
Vertical Scale
Knob
- -
Content Conventions in this Manual
DHO800 series digital oscilloscope includes the following models. Four-channel
models and two-channel models share the same operation method. Unless otherwise
specified, this manual takes the four-channel model DHO814 as an example to
illustrate the operation methods of DHO800 series oscilloscope.
Model Max. Analog Bandwidth No. of Analog Channels
DHO802 70 MHz 2+EXT
DHO804 70 MHz 4
DHO812 100 MHz 2+EXT
DHO814 100 MHz 4
Document Overview
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
9

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
