After setup, click or tap the key at the upper-right corner of the front panel to
save the waveform based on the settings. The location where the file is saved
depends on the
File Path setting in Storage menu. For details, please refer to
To Save
a File
.
Save Setup
Click or tap
Save Setup, then Operation is set to "Save Setup".
After setup, click or tap the
key at the upper-right corner of the front panel to
save the setup file suffixed with ".stp". The location where the file is saved depends on
the
File Path setting in Storage menu. For details, please refer to
To Save a File
.
All Measurements
• Click or tap
All Measure, then Operation is set to "All Measure".
• In All Measure item, click or tap the drop-down button to select the channel
(CH1-CH4) to measure.
After setup, click or tap the
key at the upper-right corner of the front panel to
perform the measurement on the specified channel.
Reset Statistics
• Click or tap
Stat Reset, then Operation is set to "Stat Reset".
• Click or tap "Measure" or "Pass/Fail" under Stat Reset to reset all statistics of the
"Measure" or "Pass/Fail" function.
After setup, click or tap the
key at the upper-right corner of the front panel.
This resets all statistics of the specified function in the
Result sidebar at the right side
of the screen and starts the measurements again.
Waveform Recording
Click or tap
Record, then Operation is set to "Record".
After setup, click or tap the
key at the upper-right corner of the front panel to
perform the waveform recording.
Save Group
• Click or tap
Save Group, then Operation is set to "Save Group".
• Under Save Group, select one or more items from "Save Image", "Save Wave",
and "Save Setup".
System Utility Function Setting
DHO800 User Guide
222
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
