Rigol DHO800 Series User Manual

- If the channel is displayed but not selected, you can press the channel key to
select the channel.
- If the channel is both displayed and selected, you can press the channel key
to close its display in the waveform view.
NOTE
As DHO802/DHO812 is a two-channel model, it only provides two channel keys (
and
).
12. Probe Compensation Signal Output Terminal/Ground Terminal
This terminal outputs the probe compensation signal which helps you match a
probe's input capacitance to the oscilloscope channel to which it is connected.
13. External Trigger Input Terminal (for DHO812 and DHO802 only)
BNC connector to input external trigger signal.
14.
Analog Channel Input Terminals
BNC connectors. Attach probes to these connectors for analog signal inputs.
NOTE
As DHO802/DHO812 is a two-channel model, it only provides two analog input terminals.
15. USB HOST Port
This series supports USB storage device of FAT32/NTFS format and mouse.
- USB storage device: imports or exports data (software update, waveform,
setup, or captured image).
- Mouse: connects a mouse to control the instrument.
16. Power Key
Powers on/off the oscilloscope.
Quick Start
DHO800 User Guide
22
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
