Rigol DHO800 Series User Manual

21 System Utility Function Setting ..............................................................................214
21.1 I/O Setting .........................................................................................................................................214
21.2 Basic Settings ................................................................................................................................... 216
21.3 About this Oscilloscope ................................................................................................................218
21.4 Other Settings ..................................................................................................................................219
21.5 Auto Config .......................................................................................................................................219
21.6 SelfCal .................................................................................................................................................220
21.7 Option List .........................................................................................................................................220
21.8 Quick Action Settings ....................................................................................................................220
21.9 Self-check .......................................................................................................................................... 223
22 Remote Control ............................................................................................................224
22.1 Remote Control via USB ...............................................................................................................225
22.2 Remote Control via LAN ...............................................................................................................225
23 Troubleshooting ...........................................................................................................227
24 Appendix ........................................................................................................................228
24.1 Appendix A: Options and Accessories .................................................................................... 228
24.2 Appendix B: Warranty ................................................................................................................... 228
24.3 Appendix C: Factory Settings ..................................................................................................... 229
DHO800 User Guide
VI
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

Rigol DHO800 Series Specifications

General

Channels	2 or 4 analog channels
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Power Supply	100-240 VAC, 50/60 Hz
Waveform Capture Rate	1, 000, 000 wfm/s
Interfaces	USB Host, USB Device, LAN
Digital Channels	Optional 16-channel MSO
Protocols Decoding	I2C, SPI, UART, CAN, LIN
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video, Slope, Pattern, Duration, Timeout, Runt, Window
