RIGOL 2 Command System
2-106 MSO2000A/DS2000A Programming Guide
:FUNCtion:WANalyze:SETup:SFRame
:FUNCtion:WANalyze:SETup:EFRame
Syntax
:FUNCtion:WANalyze:SETup:SFRame <sframe>
:FUNCtion:WANalyze:SETup:SFRame?
:FUNCtion:WANalyze:SETup:EFRame <eframe>
:FUNCtion:WANalyze:SETup:EFRame?
Description
Set or query the start frame number or end frame number of waveform analysis.
Parameter
Name Type Range Default
<sframe> Integer
1 to the maximum number
of frames recorded
1
<eframe> Integer
1 to the maximum number
of frames recorded
The maximum number of frames
recorded
Return Format
The query returns an integer.
:FUNCtion:WANalyze:SETup:THReshold
Syntax
:FUNCtion:WANalyze:SETup:THReshold <NR1>
:FUNCtion:WANalyze:SETup:THReshold?
Description
Set or query the threshold of waveform analysis and the unit is %.
Parameter
Name Type Range Default
<NR1> Integer 1 to 99 70
Explanation
The threshold is used to judge whether the data frame is an error frame. The data frame will be judged as
an error frame if the (relative) difference between it and the template is greater than or equal to the
threshold currently set.
Return Format
The query returns an integer between 1 and 99.
