RIGOL 2 Command System
2-170 MSO2000A/DS2000A Programming Guide
:MEASure:PWIDth
Syntax 1
:MEASure:PWIDth <chan>
Description 1
Enable the positive pulse width measurement function of the specified channel.
Syntax 2
:MEASure:PWIDth? <chan>
Description 2
Enable the positive pulse width measurement function of the specified channel and return the
measurement result.
Parameter
Name Type Range Default
<chan> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|
D12|D13|D14|D15|CHANnel1|CHANnel2|MATH}
--
Return Format
The query returns the measurement result in scientific notation.
Example
:MEASure:PWIDth? CHANnel1
:MEASure:PWIDth? CHANnel1
You can use the following commands to query the statistic maximum, minimum, current value, average
and standard deviation of the positive pulse width measurement values of the specified channel
waveform. Sending the following commands will enable the statistic function automatically.
 :MEASure:PWIDth:SMAXimum?
 :MEASure:PWIDth:SMINimum?
 :MEASure:PWIDth:SCURrent?
 :MEASure:PWIDth:SAVerage?
 :MEASure:PWIDth:SDEViation?
