RIGOL 2 Command System
2-24 MSO2000A/DS2000A Programming Guide
:BUS<n>:RS232 (Option)
 :BUS<n>:RS232:TX
 :BUS<n>:RS232:RX
 :BUS<n>:RS232:POLarity
 :BUS<n>:RS232:ENDian
 :BUS<n>:RS232:BAUD
 :BUS<n>:RS232:BUSer
 :BUS<n>:RS232:DBITs
 :BUS<n>:RS232:SBITs
 :BUS<n>:RS232:PARity
 :BUS<n>:RS232:PACKet
 :BUS<n>:RS232:PEND
 :BUS<n>:RS232:TTHReshold
 :BUS<n>:RS232:RTHReshold
 :BUS<n>:RS232:OFFSet
:BUS<n>:RS232:TX
Syntax
:BUS<n>:RS232:TX <source>
:BUS<n>:RS232:TX?
Description
Set or query the TX channel source of RS232 decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<source> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|
D12|D13|D14|D15|CHANnel1|CHANnel2|OFF}
CHANnel1
Explanation
When OFF is selected, no TX channel source will be set. The TX channel source and RX channel source
cannot both be set to OFF.
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1,
CHAN2 or OFF.
