Rigol DS2302A Programming Guide

RIGOL 2 Command System
2-130 MSO2000A/DS2000A Programming Guide
:MASK:OUTPut
Syntax
:MASK:OUTPut <type>
:MASK:OUTPut?
Description
Set or query the output mode when the test fails.
Parameter
Name Type Range Default
<type> Discrete {FAIL|FSOund} FAIL
Explanation
 FAIL: when a failed waveform is detected, the oscilloscope displays the statistic results and outputs a
pulse; but the beeper does not sound.
 FSOund: when a failed waveform is detected, the oscilloscope displays the statistic results and
outputs a pulse; while at the same time, the beeper sounds (not related to the on/off state of the
sound).
Return Format
The query returns FAIL or FSO.
:MASK:X
:MASK:Y
Syntax
:MASK:X <x>
:MASK:X?
:MASK:Y <y>
:MASK:Y?
Description
Set or query the horizontal or vertical adjustment parameter of the pass/fail test mask.
Parameter
Name Type Range Default
<x> Real 0.02 to 4, the step is 0.02 0.24
<y> Real 0.04 to 5.12, the step is 0.04 0.48
Return Format
The query returns the current parameter in scientific notation.
