2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-113
:LA:DISPlay
Syntax
:LA:DISPlay {<digital>|<group>|<pod>},<state>
:LA:DISPlay? {<digital>|<group>|<pod>}
Description
Turn on or off the specified digital channel, user-defined channel group or default channel group; or
query the status of the specified digital channel or channel group.
Parameter
Name Type Range Default
<digital> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|
D10|D11|D12|D13|D14|D15}
D0
<group> Discrete {GROup1|GROup2|GROup3|GROup4} --
<pod> Discrete {POD1|POD2} --
<state> Bool {{0|OFF}|{1|ON}} --
Explanation
 <group> denotes the user-defined channel groups. You can use the
:LA:GROup<n>:APPend
command to add digital channels into the 4 user-defined digital channel groups.
 <pod> denotes the default channel groups: POD1 (D0~D7) and POD2 (D8~D15).
 You can use the
:LA:ACTive command to set the digital channels or user-defined channel groups
currently turn on as the active channel or channel group.
Return Format
The query returns 0 or 1.
:LA:AUTosort
Syntax
:LA:AUTosort <n>
Description
Digital channel auto ordering mode.
Parameter
Name Type Range Default
<n> Discrete {0|1} 1
Explanation
 n=0: digital channel waveforms the on the screen are D0-D15 from top to bottom
 n=1: digital channel waveforms on the screen are D15-D0 from top to bottom
