Page #252 background image
RIGOL 2 Command System
2-236 MSO2000A/DS2000A Programming Guide
[:SOURce<n>]:APPLy:NOISe
[:SOURce<n>]:APPLy:PULSe
[:SOURce<n>]:APPLy:RAMP
[:SOURce<n>]:APPLy:SINusoid
[:SOURce<n>]:APPLy:SQUare
[:SOURce<n>]:APPLy:USER
Syntax
[:SOURce<n>]:APPLy:NOISe [<amp>[,<offset>]]
[:SOURce<n>]:APPLy:PULSe [<freq>[,<amp>[,<offset>]]]
[:SOURce<n>]:APPLy:RAMP [<freq>[,<amp>[,<offset>[,<phase>]]]]
[:SOURce<n>]:APPLy:SINusoid [<freq>[,<amp>[,<offset>[,<phase>]]]]
[:SOURce<n>]:APPLy:SQUare [<freq>[,<amp>[,<offset>[,<phase>]]]]
[:SOURce<n>]:APPLy:USER [<freq>[,<amp>[,<offset>[,<phase>]]]]
Description
Configure the specified signal source channel to output a signal with the specified waveform and
parameters.
Parameter
Name Type Range Default
<freq> Real
Sine: 100mHz to 25MHz
Square: 100mHz to 15MHz
Ramp: 100mHz to 100kHz
Pulse: 100mHz to 1MHz
Arbitrary waveform: 100mHz to 10MHz
1kHz
<amp> Real
HighZ: 20mVpp to 5Vpp
50Ω: 10mVpp to 2.5Vpp
5Vpp
<offset> Real
HighZ: ±(2.5-current amplitude/2)
50Ω: ±(1.25-current amplitude /2)
0VDC
<phase> Real to 360°
<n> Discrete {1|2} 1
Explanation
These commands are used to select the waveform shape.
NOISe: noise
PULSe: pulse
RAMP: ramp
