2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-115
:LA:DIGital<n>:DISPlay
Syntax
:LA:DIGital<n>:DISPlay <bool>
:LA:DIGital<n>:DISPlay?
Description
Turn on or off the specified digital channel; or query the status of the specified digital channel.
Parameter
Name Type Range Default
<n> Discrete {0|1|2|3|4|5|6|7|8|9|10|11|12|13|14|15} --
<bool> Bool {{0|OFF}|{1|ON}} 0|OFF
Explanation
You can set the channels or user-defined channel groups currently turned on as the active channel or
channel group using the
:LA:ACTive command.
Return Format
The query returns 0 or 1.
:LA:DIGital<n>:POSition
Syntax
:LA:DIGital<n>:POSition <position>
:LA:DIGital<n>:POSition?
Description
Set or query the display position of the specified digital channel.
Parameter
Name Type Range Default
<n> Discrete {0|1|2|3|4|5|6|7|8|9|10|11|12|13|14|15} --
<position> Integer
When the waveform display mode is SMALl: 0 to 15
When the waveform display mode is LARGe: 0 to 7
--
Explanation
For the waveform display size, refer to the
:LA:SIZE command.
Return Format
The query returns an integer from 0 to 15 or from 0 to 7.
