Page #328 background imageLoading...
Page #328 background image
RIGOL 2 Command System
2-312 MSO2000A/DS2000A Programming Guide
:TRIGger:SPI
:TRIGger:SPI:CLEVel
:TRIGger:SPI:DLEVel
:TRIGger:SPI:DATA
:TRIGger:SPI:SCL
:TRIGger:SPI:SDA
:TRIGger:SPI:SLOPe
:TRIGger:SPI:TIMeout
:TRIGger:SPI:WIDTh
:TRIGger:SPI:CLEVel
:TRIGger:SPI:DLEVel
Syntax
:TRIGger:SPI:CLEVel <level>
:TRIGger:SPI:CLEVel?
:TRIGger:SPI:DLEVel <level>
:TRIGger:SPI:DLEVel?
Description
Set or query the trigger level of SCL or SDA in SPI trigger. The unit is the same with the current amplitude
unit.
Parameter
Name Type Range Default
<level> Real
When the clock source or data source is CHANnel1 or CHANnel2:
-5×VerticalScale–OFFSet to +5×VerticalScale–OFFSet
When the clock source or data source is any of D0-D15: -20V to 20V
0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Return Format
The query returns the trigger level in scientific notation.
