Rigol DS2302A - Measure:setup:dsa; Measure:setup:dsb

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-143
:MEASure:SETup:DSA
:MEASure:SETup:DSB
Syntax
:MEASure:SETup:DSA <sourceA>
:MEASure:SETup:DSA?
:MEASure:SETup:DSB <sourceB>
:MEASure:SETup:DSB?
Description
Set or query the channel source of source A or B in delay 1
→2 , delay 1 →2 , delay 1 →2 and
delay 1
→2 measurements.
Parameter
Name Type Range Default
<sourceA> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|D12|
D13|D14|D15|CHANnel1|CHANnel2 }
CHANnel1
<sourceB> Discrete
When <sourceA> is D0-D15:
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|D12|D13|D14|
D15}
When <sourceA> is CHANnel1 or CHANnel2:
{CHANnel1|CHANnel2}
CHANnel2
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1 or
CHAN2.
