Rigol DS2302A Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-57
:CALCulate:LOGic
 :CALCulate:LOGic:SA
 :CALCulate:LOGic:SB
 :CALCulate:LOGic:INVert
 :CALCulate:LOGic:VSCale
 :CALCulate:LOGic:VOFFset
 :CALCulate:LOGic:OPERator
 :CALCulate:LOGic:ATHReshold
 :CALCulate:LOGic:BTHReshold
:CALCulate:LOGic:SA
:CALCulate:LOGic:SB
Syntax
:CALCulate:LOGic:SA <source>
:CALCulate:LOGic:SA?
:CALCulate:LOGic:SB <source>
:CALCulate:LOGic:SB?
Description
Set or query the channel source of signal source A or B of the logic operation.
Parameter
Name Type Range Default
<source> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
CHANnel1
Explanation
If the current logic operation type is NOT, only use the the :CALCulate:LOGic:SA command to specify the
channel source of signal source A.
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1 or
CHAN2.
