RIGOL 2 Command System
2-58 MSO2000A/DS2000A Programming Guide
:CALCulate:LOGic:INVert
Syntax
:CALCulate:LOGic:INVert <bool>
:CALCulate:LOGic:INVert?
Description
Enable or disable the inverted display of the logic operation result; or query the current status of the
inverted display of the logic operation result.
Parameter
Name Type Range Default
<bool> Bool {{0|OFF}|{1|ON}} 0|OFF
Return Format
The query returns 0 or 1.
:CALCulate:LOGic:VSCale
Syntax
:CALCulate:LOGic:VSCale <scale>
:CALCulate:LOGic:VSCale?
Description
Set or query the vertical scale of the logic operation result.
Parameter
Name Type Range Default
<scale> Real 0.05U to 100U 1U
Return Format
The query returns the vertical scale in scientific notation.
