Rigol DS2302A Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-69
:CHANnel<n>:OFFSet
Syntax
:CHANnel<n>:OFFSet <offset>
:CHANnel<n>:OFFSet?
Description
Set or query the vertical offset of the specified analog channel. The default unit is V.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<offset> Real
When the input impedance is 50Ω and the
probe ratio is 1X:
500μV/div to 50mV/div: -2V to 2V
51mV/div to 200mV/div: -10V to 10V
205mV/div to 1V/div: -12V to 12V
When the input impedance is 1MΩ and the
probe ratio is 1X:
500μV/div to 50mV/div: -2V to 2V
51mV/div to 200mV/div: -10V to 10V
205mV/div to 2V/div: -50V to 50V
2.05V/div to 10V/div: -100V to 100V
CHANnel1: 2V
CHANnel2: -2V
Note: The range of the vertical offset is related to the vertical scale, probe ratio and input impedancecurrently set.
For the vertical scale, refer to the :CHANnel<n>:SCALe command. For the probe ratio, refer to
the
:CHANnel<n>:PROBe command. For the input impedance, refer to the :CHANnel<n>:IMPedance command.
Return Format
The query returns the vertical offset in scientific notation.
