2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-19
:BUS<n>:PARallel
 :BUS<n>:PARallel:CLK
 :BUS<n>:PARallel:SLOPe
 :BUS<n>:PARallel:BSET
 :BUS<n>:PARallel:THReshold
 :BUS<n>:PARallel:OFFSet
:BUS<n>:PARallel:CLK
Syntax
:BUS<n>:PARallel:CLK <sour>
:BUS<n>:PARallel:CLK?
Description
Set or query the clock channel source of parallel decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<sour> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|
D12|D13|D14|D15|CHANnel1|CHANnel2|OFF}
CHANnel1
Explanation
When OFF is selected, no clock channel is set and the oscilloscope samples data once the channel data
jumps. At this point, the edge set by the
:BUS<n>:PARallel:SLOPe command can be ignored.
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1,
CHAN2 or OFF.
