RIGOL 2 Command System

2-280 MSO2000A/DS2000A Programming Guide

:TRIGger:IIC:AWIDth

Syntax

:TRIGger:IIC:AWIDth <bits>

:TRIGger:IIC:AWIDth?

Description

Set or query

the number of bits of the address in I2C trigger when the trigger condition is Address or

A&D.

Parameter

Name Type Range Default

<bits> Discrete {7|8|10} 7

Explanation

To set the I2C trigger condition, refer to the

:TRIGger:IIC:WHEN command.

Return Format

The query returns 7, 8 or 10.
