RIGOL 2 Command System
2-282 MSO2000A/DS2000A Programming Guide
:TRIGger:IIC:DIRection
Syntax
:TRIGger:IIC:DIRection <dir>
:TRIGger:IIC:DIRection?
Description
Set or query the data direction in I2C trigger when the trigger condition is Address or A&D.
Parameter
Name Type Range Default
<dir> Discrete {READ|WRITe|RWRite} READ
Explanation
To set the I2C trigger condition, refer to the
:TRIGger:IIC:WHEN command.
Return Format
The query returns READ, RIT or RWR.
:TRIGger:IIC:SCL
:TRIGger:IIC:SDA
Syntax
:TRIGger:IIC:SCL <scl>
:TRIGger:IIC:SCL?
:TRIGger:IIC:SDA <sda>
:TRIGger:IIC:SDA?
Description
Set or query the SCL or SDA channel source in IIC trigger.
Parameter
Name Type Range Default
<scl> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
CHANnel1
<sda> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
CHANnel2
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1 or
CHAN2.
