2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-285
:TRIGger:NEDGe:LEVel
Syntax
:TRIGger:NEDGe:LEVel <level>
:TRIGger:NEDGe:LEVel?
Description
Set or query the trigger level in Nth edge trigger. The unit is the same with the current amplitude unit.
Parameter
Name Type Range Default
<level> Real
When the trigger source is CHANnel1 or CHANnel2:
-5×VerticalScale–OFFSet to +5×VerticalScale–OFFSet
When the trigger source is any of D0-D15: -20V to 20V
0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Return Format
The query returns the trigger level in scientific notation.
:TRIGger:NEDGe:SLOPe
Syntax
:TRIGger:NEDGe:SLOPe <slope>
:TRIGger:NEDGe:SLOPe?
Description
Set or query the edge type of Nth edge trigger.
Parameter
Name Type Range Default
<slope> Discrete {POSitive|NEGative} POSitive
Return Format
The query returns POSitive or NEGative.
