Rigol DS2302A Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-291
:TRIGger:PULSe:LWIDth
Syntax
:TRIGger:PULSe:LWIDth <width>
:TRIGger:PULSe:LWIDth?
Description
Set or query the lower limit of the pulse width in pulse trigger. The unit is s.
Parameter
Name Type Range Default
<width> Real
and : 2ns to 4s
and : 2ns to 3.99s
1us
Explanation
This command is available when the trigger condition (refer to
:TRIGger:PULSe:WHEN command) is
PGReater (
), NGReater ( ), PGLess ( ) or NGLess ( ).
Return Format
The query returns the lower limit of the pulse width in scientific notation.
:TRIGger:PULSe:SOURce
Syntax
:TRIGger:PULSe:SOURce <source>
:TRIGger:PULSe:SOURce?
Description
Set or query the trigger source in pulse trigger.
Parameter
Name Type Range Default
<source> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2|EXT}
CHANnel1
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1,
CHAN2 or EXT.
