RIGOL
2
Command System
2-
302
MSO2000A/DS2000A
Pro
gramm
ing Gui
de
:TRIGger:
RUNT:WUPPer
Syntax
:TRIGger:
RUNT
:WUPPer
<NR3>
:TRIGger:
RUNT
:WUPPer?
Descri
ption
Set or query
the upper limit of the pulse width in runt trigger.
Parameter
Name
Type
Ran
ge
Default
<NR3>
Discrete
When the qualif
ier is
<: 2
ns
to
4s
When the qualif
ier is <>
:
10ns
to
4s
2us
Return Format
The query returns the upper limit of the pulse width in scientific notation.
317
319
Table of Contents
Guaranty and Declaration
3
Document Overview
4
Table of Contents
5
SCPI Overview
13
Syntax
13
Symbol Description
14
Parameter Type
14
Command Abbreviation
15
Command System
17
Autoscale
18
Clear
18
Run
18
Stop
18
Single
19
Tforce
19
Tlhalf
19
IEEE 488.2 Common Commands
20
Cls
20
Ese
21
Esr
22
Idn
22
Opc
23
Rst
23
Sre
24
Stb
25
Tst
26
Acquire Commands
27
Acquire:averages
27
Acquire:mdepth
28
Acquire:srate
28
Acquire:type
29
Acquire:aalias
30
Bus<N> Commands
31
Bus<N>:Mode
31
Bus<N>:Display
32
Bus<N>:Format
32
Bus<N>:Event
33
Bus<N>:Eexport
33
Bus<N>:Data
34
Bus<N>:Parallel
35
Bus<N>:Rs232 (Option)
40
Bus<N>:IIC (Option)
48
Bus<N>:Spi (Option)
52
Calculate Commands
58
Calculate:mode
58
Calculate:add
59
Calculate:sub
61
Calculate:multiply
63
Calculate:division
65
Calculate:fft
67
Calculate:logic
73
Calculate:advanced
77
Calibrate Commands
80
Calibrate:date
80
Calibrate:start
80
Calibrate:time
81
Calibrate:quit
81
Channel<N> Commands
82
Channel<N>:Bwlimit
82
Channel<N>:Coupling
83
Channel<N>:Display
83
Channel<N>:Invert
84
Channel<N>:Impedance
84
Channel<N>:Offset
85
Channel<N>:Scale
86
Channel<N>:Probe
87
Channel<N>:Units
87
Channel<N>:Vernier
88
Channel<N>:Tcal
89
Cursor Commands
90
Cursor:mode
90
Cursor:manual
91
Cursor:track
99
Display Commands
104
Display:clear
104
Display:type
105
Display:grading:time
106
Display:wbrightness
106
Display:grid
107
Display:gbrightness
107
Display:mpersistence
108
Display:data
108
Function Commands
110
Function:wrmode
110
Function:wrecord
111
Function:wreplay
114
Function:wanalyze
119
LA Commands (MSO2000A/MSO2000A-S)
127
La:state
127
La:active
128
La:display
129
La:autosort
129
La:delete
130
La:size
130
La:digital<N>:Display
131
La:digital<N>:Position
131
La:digital<N>:Label
132
La:pod<N>:Display
132
La:pod<N>:Threshold
133
La:group<N>:Append
133
La:bus<N>:Current
134
La:bus<N>:Display
134
La:bus<N>:Channel
135
La:bus<N>:Format
135
LAN Commands
136
Lan:dhcp
136
Lan:autoip
137
Lan:gateway
138
Lan:dns
138
Lan:mac
139
Lan:manual
139
Lan:initiate
140
Lan:ipaddress
140
Lan:smask
141
Lan:status
141
Lan:visa
141
Lan:apply
142
MASK Commands
143
Mask:enable
143
Mask:source
144
Mask:operate
144
Mask:mdisplay
145
Mask:sooutput
145
Mask:output
146
Mask:X
146
Mask:y
146
Mask:create
147
Mask:passed
147
Mask:failed
147
Mask:total
148
Mask:reset
148
Mask:data
149
Measure Commands
150
Measure:source
151
Measure:counter:source
152
Measure:counter:value
152
Measure:clear
153
Measure:recover
153
Measure:adisplay
154
Measure:amsource
154
Measure:statistic:display
155
Measure:statistic:mode
155
Measure:statistic:reset
156
Measure:setup:type
156
Measure:setup:max
157
Measure:setup:MID
157
Measure:setup:min
157
Measure:setup:psa
158
Measure:setup:psb
158
Measure:setup:dsa
159
Measure:setup:dsb
159
Measure:area
160
Measure:cregion:cax
160
Measure:cregion:cbx
160
Measure:history:display
161
Measure:history:dmode
161
Measure:fdelay
162
Measure:f2Rdelay
164
Measure:fphase
166
Measure:f2Rphase
168
Measure:frequency
170
Measure:ftime
172
Measure:nduty
174
Measure:nwidth
176
Measure:overshoot
178
Measure:pduty
180
Measure:period
182
Measure:preshoot
184
Measure:pwidth
186
Measure:rtime
188
Measure:rdelay
190
Measure:r2Fdelay
192
Measure:rphase
194
Measure:r2Fphase
196
Measure:vamp
198
Measure:vavg
200
Measure:vbase
202
Measure:vmax
204
Measure:vmin
206
Measure:vpp
208
Measure:vrms
210
Measure:pvrms
212
Measure:vtop
214
Measure:marea
216
Measure:mparea
218
Output<N> Commands (MSO2000A-S/DS2000A-S)
220
Output[<N>][:State]
220
Output[<N>]:Impedance
220
Recall Commands
221
Recall:setup
221
Recall:trace
222
Recall:waveform
222
Reference Commands
223
Reference<N>:Current
223
Reference<N>:Enable
224
Reference:color
224
Reference:current
225
Reference:display
225
Reference:reset
225
Reference:save
226
Reference:source
226
Reference:vscale
227
Reference:voffset
228
SAVE Commands
229
Save:csv[:Start]
230
Save:csv:factors
231
Save:csv:length
231
Save:format
232
Save:image[:Start]
232
Save:image:type
233
Save:image:factors
233
Save:setup[:Start]
234
Save:trace[:Start]
235
Save:waveform[:Start]
235
Save:reference[:Start]
236
Save:mtest[:Start]
237
Save:arb[:Start]
238
Source<N> Commands (MSO2000A-S/DS2000A-S)
239
[:Source<N>]:Frequency[:Fixed]
240
[:Source<N>]:Phase[:Adjust]
240
[:Source<N>]:Phase:initiate
241
[:Source<N>]:Function[:Shape]
242
[:Source<N>]:Function:ramp:symmetry
243
[:Source<N>]:Voltage[:Level][:Immediate][:Amplitude]
244
[:Source<N>]:Voltage[:Level][:Immediate]:Offset
245
[:Source<N>]:Pulse:dcycle
246
[:Source<N>]:Mod[:State]
247
[:Source<N>]:Mod:type
248
[:Source<N>]:Mod:am[:Depth]
248
[:Source<N>]:Mod:am:internal:frequency
249
[:Source<N>]:Mod:am:internal:function
249
[:Source<N>]:Mod:fm[:Deviation]
250
[:Source<N>]:Mod:fm:internal:frequency
250
[:Source<N>]:Mod:fm:internal:function
251
[:Source<N>]:Apply:noise
252
[:Source<N>]:Apply:pulse
252
[:Source<N>]:Apply:ramp
252
[:Source<N>]:Apply:sinusoid
252
[:Source<N>]:Apply:square
252
[:Source<N>]:Apply:user
252
[:Source<N>]:Apply
254
System Commands
255
System:aoutput
256
System:autoscale
256
System:beeper
257
System:date
257
System:error[:Next]
258
System:expand
258
System:gamount
259
System:gpib
259
System:key:press
260
System:key:increase
262
System:key:decrease
262
System:language
263
System:option:install
263
System:option:uninstall
263
System:option:valid
264
System:pon
264
System:pstatus
265
System:ramount
265
System:reset
265
System:ssaver:time
266
System:setup
266
System:time
267
System:udevice
267
System:version
268
Timebase Commands
269
Timebase:delay:enable
269
Timebase:delay:offset
270
Timebase:delay:scale
270
Timebase[:Main]:Offset
271
Timebase[:Main]:Scale
272
Timebase:href:mode
273
Timebase:href:position
273
Timebase:mode
274
Timebase:vernier
274
Trace<N> Commands (MSO2000A-S/DS2000A-S)
275
[:Trace<N>]:Data
275
[:Trace<N>]:Data:dac16
276
[:Trace<N>]:Data:dac
277
[:Trace<N>]:Data:load
278
[:Trace<N>]:Data:points
278
[:Trace<N>]:Data:points:interpolate
279
[:Trace<N>]:Data:value
280
Trigger Commands
281
Trigger:coupling
282
Trigger:holdoff
282
Trigger:mode
283
Trigger:nreject
283
Trigger:status
284
Trigger:sweep
285
Trigger:delay (Option)
286
Trigger:duration (Option)
289
Trigger:edge
293
Trigger:IIC
295
Trigger:nedge (Option)
300
Trigger:pattern
303
Trigger:pulse
306
Trigger:rs232
310
Trigger:runt
315
Trigger:shold
319
Trigger:slope
323
Trigger:spi
328
Trigger:timeout (Option)
332
Trigger:usb (Option)
334
Trigger:video (HDTV Option)
337
Trigger:windows (Option)
342
Waveform Commands
345
Waveform:source
346
Waveform:mode
347
Waveform:format
348
Waveform:points
348
Waveform:data
349
Waveform:xincrement
351
Waveform:xorigin
352
Waveform:xreference
352
Waveform:yincrement
352
Waveform:yorigin
353
Waveform:yreference
353
Waveform:start
354
Waveform:stop
355
Waveform:begin
355
Waveform:end
355
Waveform:reset
356
Waveform:preamble
356
Waveform:status
357
Programming Demos
359
Programming Preparations
360
Excel Programming Demo
361
Labview Programming Demo
365
Matlab Programming Demo
369
Visual Basic 6.0 Programming Demo
371
Visual C++ 6.0 Programming Demo
373
